fi-7300NX
fi-7300NX cloud ready with data encryption
fi-7300NX cloud ready with data encryption, make centralized document management from remote locations simple and cost-effective. Choose the network-enabled fi-7300NX, complete with a network-enabled scanner and secure hosted cloud environment.
View Document and Downloads
View Accessories & Consumables
Scanner Information
fi-7300NX cloud ready with data encryption
Boasts a speed of 60 ppm/120 ipm (200/300 dpi) for scanning A4 portraits, loads up to 80 sheets at a time.
Users can scan and save documents without any requirement for a local computer. They can simply login to the scanner using user authentication and select a job from their personalized job menus on the fi-7300NX’s touch screen. Customized job menus ensure efficient and secure decentralized data entry is possible for each user.
The fi-7300NX supports NFC* (Type-A [MIFARE], Type-B, and FeliCa) authentication and user authentication with username and password input on the touch screen. It is also possible for different job menus to be assigned to each scanner, and avoid any authentication processes.
Easy Operation
Easy to share and manage, so users don't need any training.
Compatibility
Network-enabled scanning with PaperStream IP Net makes it easy to connect to any scanning software.
Cloud Ready
Securely scans your data to cloud locations with a touch of a button.
Optional EdgeXperience or NX Manager Install
Server management wherever you need it, SaaS, private cloud, or local.
| Category | Specification | Description |
|---|---|---|
| Scanner Type | ADF (Automatic Document Feeder)/Manual Feed, Duplex | |
| Scanning Speed*1 (A4 Portrait) (Color*2/Grayscale*2 /Monochrome*3) |
Simplex: 60 ppm (200/300 dpi) Duplex: 120 ipm (200/300 dpi) |
|
| Image Sensor Type | Color CCD x 2 (front x 1, back x 1) | |
| Light Source | White LED Array x 2 (front x 1, back x 1) | |
| Optical Resolution | 600 dpi | |
| Output Resolution*4 (Color / Grayscale / Monochrome) |
50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver)*5 | |
| Output Format | Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit | |
| Background Colors | White / Black (selectable) | |
| Document Size | ||
| Maximum*6 | 216 x 355.6 mm (8.5 x 14 in.) | |
| Minimum*7 | 50.8 x 54 mm (2 x 2.1 in.) | |
| Long Page Scanning*8 | 5,588 mm (220 in.) | |
| Paper Weight (Thickness) | ||
| Paper | 27 to 413 g/m² (7.2 to 110 lb)*9 | |
| Plastic Card | 1.4 mm (0.055 in.) or less*10 | |
| ADF Capacity*11*12 | 80 sheets (A4 80 g/m² or Letter 20 lb) | |
| Expected Daily Volume*13 | 9,000 sheets | |
| Multifeed Detection | Overlap detection (Ultrasonic sensor), Length detection | |
| Paper Protection | Lag detection, Sound detection (iSOP)*14 | |
| Display | 4.3 in. TFT color touch screen | |
| Authentication | Keyboard (on touch screen), NFC | |
| Interface | ||
| USB | USB 3.1 Gen1 / USB 2.0 / USB 1.1 | |
| Ethernet | 10BASE-T, 100BASE-TX, 1000BASE-T | |
| Wi-Fi | IEEE802.11 a/b/g/n/ac Frequency band: 2.4 GHz / 5 GHz*15 |
|
| Wi-Fi Interface | ||
| Rated Power (EIRP) (North America) |
2.4 GHz: 11b: +23.5dBm, 11g: +22.0dBm, 11n/ac: +22.0dBm (20/40MHz) 5 GHz*15: 11a: +15.5dBm, 11n/ac: +16.5dBm (20MHz) |
|
| Rated Power (EIRP) (Others) |
2.4 GHz: 11b: +19.0dBm, 11g: +20.5dBm, 11n/ac: +20.5dBm (20/40MHz) 5 GHz*15: 11a: +15.5dBm, 11n/ac: +16.5dBm (20MHz) |
|
| Network Protocols | IPv4*16, TCP, UDP, ICMP, DHCP, HTTP/HTTPS, DNS | |
| Power Requirements | AC 100 to 240 V ±10 % | |
| Power Consumption*17 | ||
| Operating | 42 W or less | |
| Power Saving | 2.4 W or less | |
| Power Off | 0.35 W or less | |
| Operating Environment | ||
| Temperature | 5 to 35 °C (41 to 95 °F) | |
| Relative Humidity | 20 to 80% (Non-condensing) | |
| Environmental Compliance | ENERGY STAR, RoHS | |
| Dimensions*18 (W x D x H) | 300 x 202 x 170 mm (11.8 x 7.9 x 6.6 in.) | |
| Weight | 4.9 kg (10.8 lb) or less | |
| Supported Operating System | Windows 11*19, Windows 10*19, Windows Server 2025, Windows Server 2022, Windows Server 2019, Windows Server 2016. Find more information for PaperStream NX Manager. |
|
| Software / Drivers*21 | PaperStream IP Driver (TWAIN/TWAIN x64/ISIS™), WIA Driver*20, PaperStream Capture, PaperStream ClickScan, Software Operation Panel, Network Setup Tool, Error Recovery Guide, ABBYY FineReader for ScanSnap™, PaperStream Central Admin | |
| Image Processing Functions | Error diffusion, Dither | |
| Included Items | Chuter unit, AC cable, AC adapter, USB cable, Setup DVD-ROM |
| No. | Details |
|---|---|
| 1 | Scanning speeds may vary due to the system environment. The values shown are the results of the evaluation under the following environment • Windows 10/CPU: Intel Core™ i3-10105 3.7GHz/Memory: 8GB/Storage: SSD |
| 2 | Indicated speeds are from using JPEG compression. |
| 3 | Indicated speeds are from using TIFF CCITT Group 4 compression. |
| 4 | Selectable maximum resolution may vary depending on the length of the scanned document. |
| 5 | Some limitations may apply to the size of documents that can be scanned, depending on system environment, when scanning at high resolution (over 600 dpi). |
| 6 | Scans folded documents up to 297 x 432 mm (11.7 x 17 in.) with carrier sheet scanning. |
| 7 | Supports both portrait and landscape orientation. |
| 8 | Capable of scanning documents with dimensions exceeding that of A4 (210 x 297 mm / 8.3 x 11.7 in.) sizes. When using PaperStream IP (TWAIN/ISIS™), resolutions are limited to 200 dpi or less when scanning documents ＞ 5,461 mm (215 in.) to ≦5,588 mm (220 in.). When using PaperStream NX Manager, resolutions are limited to 300 dpi or less with simplex scanning of documents ≦1828.8 mm (72 in.) and duplex scanning of documents ≦863.6 mm (34 in.). Long page scanning is not available when using PaperStream NX Manager to scan from web browsers or smart devices and thin clients. |
| 9 | Thicknesses of up to 128 to 209 g/m2 (34 to 56 lb) can be scanned for A8 (52 x 74 mm / 2.1 x 2.9 in.) sizes. |
| 10 | Capable of scanning up to 3 cards at a time (Note: does not set more than one embossed card at a time). |
| 11 | Maximum capacity varies based on paper weight. |
| 12 | Capable of setting additional documents while scanning. |
| 13 | When operating 8 hours a day. |
| 14 | Intelligent Sonic Paper Protection. |
| 15 | Availability of 5 GHz Wi-Fi may vary depending on region. |
| 16 | IPv6 is not supported. |
| 17 | Scanner automatically enters power saving mode when not used and powers off by default when not used for 4 hours. |
| 18 | Excludes ADF paper chute and stacker. |
| 19 | fi Series scanners do not run on Windows 11 and 10 ARM-based PCs. |
| 20 | Functions equivalent to those offered by PaperStream IP may not be available with the WIA Driver. |
| 21 | Refer to the fi Series Support Site for driver/software downloads and full lineup of all supported operating system versions. |
| Item | Part Number | Description |
|---|---|---|
| Consumables | ||
| Brake Roller | PA03670-0001 | Every 200,000 sheets*1 |
| Pick Roller | PA03670-0002 | Every 200,000 sheets*1 |
| Cleaner F1 | PA03950-0352 | 100 ml bottle for Roller cleaning |
| Cleaning Wipe | PA03950-0419 | 1 pack (24 sheets) for Roller cleaning |
| Cleaning Paper | CA99501-0012 | 1 pack (10 sheets) for use with Cleaner F1 |
| Options | ||
| Carrier Sheets | PA03360-0013 | Each package contains 5 carrier sheets |
| PaperStream Capture Pro Scan Station (WG)*2 |
PA43404-A665 | PaperStream Capture Pro optional license |
| PaperStream Capture Pro | PA43404-B403 | One year license of PaperStream Capture Pro |
| PaperStream Capture Pro Premium | PA43404-B421 | One year license of PaperStream Capture Pro Premium |
| Note | Details |
|---|---|
| 1 | Guidelines for using A4 documents (80 g/m2 [20 lb]). Cycles vary based on document type, scanner usage, cleaning frequency, and environment. |
| 2 | Optional license for users of PaperStream Capture Pro 4.1 or earlier. Distribution of PaperStream Capture Pro 4.1 ends January 2026. Consider using PaperStream Capture Pro/Pro Premium 5.0 or later. |
