i5250 FADGI
i5250 FADGI serious scanning power.
The most efficient way to scan, perform imaging functions, and extract data, Dynamic Flow Technology delivers optimized memory allocation and processing paths
View Document and Downloads
View Accessories & Consumables
Scanner Information
i5250 FADGI serious scanning power.
With the KODAK i5250 FADGI Scanner, you can rest assured that any digital submissions will comply with FADGI guidelines for Modern Textual Records—we guarantee it! In fact, Kodak Alaris is the only solution provider that certifies its scanners for FADGI compliance and provides a DICE (Digital Image Conformance Evaluation) test target to make ongoing performance checks and calibration as straightforward as possible.
Award-winning
Choice of the most demanding customers in the toughest scanning environments – service bureaus, business process outsourcing organizations, and corporate scanning departments.
FADGI Compliance
comply with FADGI guidelines for Modern Textual Records
Digital Image Conformance Evaluation
Kodak Alaris is the only solution provider that certifies its scanners for FADGI compliance and provides a DICE (Digital Image Conformance Evaluation) test target to make ongoing performance checks and calibration as straightforward as possible.
Intelligent Document Protection
Intelligent Document Protection listens for problems and alerts you before they become jams or misfeeds.
| Product Highlights |
The most efficient way to scan, perform imaging functions, and extract data, Dynamic Flow Technology delivers optimized memory allocation and processing paths |
| Throughput Speeds Hover over me Throughput speed may vary depending on your choice of driver application software, operating system, PC and selected image processing features. |
150 ppm (in both FADGI and non-FADGI mode) Hover over me Throughput speed may vary depending on your choice of application software, operating system, and selected image processing features. |
| Feeder Capacity |
Up to 750 sheets of 80 g/m² (20 lb.) paper |
| Connectivity |
USB 2.0 Hover over me This product has been tested and certified by USB.org USB 3.2 Gen 1x1 Compatible Hover over me USB 3.2 Gen 1x1 = USB 3.1 Gen 1 = USB 3.0 (5Gbps) |
| Maximum Document Size Hover over me The maximum document size supported by the scanner will vary based on the output image resolution and image compression used. |
305 mm x 4.6 m (12 in. x 180 in.) for non-FADGI compliant images; 305 mm x 355 mm (12in. x 14 in.) for FADGI-compliant images Hover over me These scanners support continuous scan mode |
| Paper Thickness and Weight |
45-200 g/m² (12-110 lb.) paper |
| Accessories and Consumables |
Document Extenders Feeder Consumables Kits Imaging Guide Set KODAK A3 Size Flatbed Accessory KODAK Enhanced Printer Accessory Manual Feed Shelf Printer Cleaning Pads Printer Ink Cartridge and Carrier Rear Exit Tray Accessory Switchable Background |
| Acoustical Noise |
Scanning: <56 dB(A) Standby mode: <39 dB(A) |
| Approvals and Product Certifications |
Canada (cTUVus & ICES-003) Mexico (NOM) Taiwan (BSMI) US (cTUVus & FCC) |
| Barcode Reading |
Codabar Code 128 Code 3 of 9 EAN-13 EAN-8 Interleaved 2 of 5 Not available when scanning with AQIST for FADGI complaint images PDF417 QR UPC-A UPC-E |
| Data Security |
This scanner processes scanned data exclusively through volatile memory ensuring image data is effectively erased upon shut down. Hover over me Read more about data security. |
| Dimensions and Weight |
|
| Electrical Requirements |
100-240 V (International); 50-60 Hz |
| Environmental Certification |
2008 EuP ENERGY STAR Qualified EPEAT Silver |
| Image Output Resolution Options |
Up to 600 dpi (in non-FADGI mode); 300 dpi in FADGI mode Hover over me Supported DPI: 100, 150, 200, 240, 250, 300, 400, 500, 600 |
| Minimum Document Size |
63.5 mm x 63.5 mm (2.5 in. x 2.5 in.) |
| File Format Outputs |
BMP Hover over me Native scanner and driver file format Not available when scanning with AQIST for FADGI compliant JPEG Hover over me Native scanner and driver file format Not available when scanning with AQIST for FADGI compliant images Single-page TIFF Hover over me Native scanner and driver file format |
| Operating System Compatibility |
Windows 10 Enterprise (no Home versions) 21H1/20H2 |
| Operating Temperature and Humidity |
Operating Humidity 15% - 80% RH Operating Temperature 15-35° C (59-95° F) |
| Operator Control Panel |
3.5 inch (89 mm) graphical color touchscreen LCD with operator control buttons |
| Optional Software |
Capture Pro Software Info Input Solution |
| Paper Path Options |
Documents can exit into the front output tray, or at the rear of the scanner if the straight-through paper path option is manually selected |
| Sure Path Features |
Controlled stacking Enhanced jam recovery Intelligent Document Protection Interactive multifeed with image display on host Interactive Operator Control Panel (OCP) Length Multifeed Detection Metal (staple) detection Operator overrides Ultrasonic Multifeed Technology |
| Perfect Page Features |
Adaptive threshold processing Hover over me Not available when scanning with AQIST for FADGI compliant images Aggressive cropping Hover over me Not available when scanning with AQIST for FADGI compliant images Auto white balance Hover over me Not available when scanning with AQIST for FADGI compliant images Autocrop Automatic color balance Hover over me Not available when scanning with AQIST for FADGI compliant images Automatic color detection Hover over me Not available when scanning with AQIST for FADGI compliant images Automatic orientation Barcode reading Color-on-the-fly toggle patch Hover over me Not available when scanning with AQIST for FADGI compliant images Content-based blank page removal Deskew Electronic color dropout Hover over me Not available when scanning with AQIST for FADGI compliant images Enhanced color adjustment Hover over me Not available when scanning with AQIST for FADGI compliant images Enhanced color management Hover over me Not available when scanning with AQIST for FADGI compliant images Fixed cropping Hover over me Not available when scanning with AQIST for FADGI compliant images Fixed thresholding Hover over me Not available when scanning with AQIST for FADGI compliant images Front side printer Halftone removal Hover over me Not available when scanning with AQIST for FADGI compliant images Image hole fill Hover over me Not available when scanning with AQIST for FADGI compliant images Image merge Hover over me Not available when scanning with AQIST for FADGI compliant images iThresholding Hover over me Not available when scanning with AQIST for FADGI compliant images Lone Pixel Noise Removal Hover over me Not available when scanning with AQIST for FADGI compliant images Multicolor dropout Hover over me Not available when scanning with AQIST for FADGI compliant images Orthogonal rotation Output Compression-CCITT Group IV* JPEG*, Uncompressed Output Hover over me Not available when scanning with AQIST for FADGI compliant images Rear side printer Relative cropping Hover over me Not available when scanning with AQIST for FADGI compliant images Sharpening Hover over me Not available when scanning with AQIST for FADGI compliant images Streak filtering |
| Power Consumption |
Running: less than 215 watts Sleep Mode: less than 3.5 watts Standby: less than 0.5 watts |
| Recommended Daily Volume |
Unlimited |
| Recommended PC Configuration |
INTEL CORE i5 (Sandy Bridge or newer), running @ 2.7 GHz or higher, USB port 3.0 (Super Speed) or 2.0 (High Speed), 4 GB RAM or more Hover over me For non-FADGI scanning. INTEL i7 – 10700 2.9 GHZ, Nvidia GPU GTX1070 or similar, System Drive : SSD 2nd Hard Drive: SSD minimum 500 GB * - For creating FADGI compliant images with AQIST. |
| Scanning Technology |
Dual White LED Illumination CCD; Grayscale output bit depth is 256 levels (8-bit); color output bit depth is 24 bits (8 x 3); color capture bit depth is 48 bits (16 x 3) |
| Standard Software And Drivers |
|
KODAK A3 Size Flatbed Accessory
Includes: KODAK A3 Flatbed with black background, 2-meter (6-ft.) USB cable and power supply.
Usage: for scanning exception documents. Accommodates document sizes up to 305 x 457 mm (12 x 18 in.)
Download Brochure
